Optical Film Thickness Gauge Delta Series

Thin-film Characteristics (R) [Normal Incidence; 351nm]: R>99.85% @351nm Damage Threshold [351nm；3ns]: >12J/cm2 @351nm，3ns Thin-film Characteristics (R) [Normal Incidence; 527nm]: R>99.90% @527nm

Prism Polarizing Beamsplitter Coating (UV) - Angle of Incidence: 45º Prism Polarizing Beamsplitter Coating (UV) - Reflectance (Rs): Rs > 99.5 % Prism Polarizing Beamsplitter Coating (UV) - Transmittance (Tp): Tp > 95 %

A polarizing film refers to a type of optical thin film used to generate polarized light or suppress the polarization effect of thin films. It has a wide range of applications in optical systems, optical instruments, and laser systems.

Laser crystal coating - material: Customized according to customer requirements Laser crystal coating - dimensional tolerance: ±0.01 ~±0.2 mm Laser crystal coating - chamfer: 0.5 mm, 45 °

Boxin can customize laser crystal coatings and ITO coatings according to customer requirements.

Single Wavelength AR (UV) - Angle of Incidence: 0º or 45º Single Wavelength AR (UV) - Reflectance (λ>255 nm) (R) [λ>255 nm; unpolarized; at 0°; at 45°]: Unpolarized; R≤0.25 % at 0 °, R≤0.5 % at 45 ° Single Wavelength AR (UV) - Reflectance (λ≤255nm) (R) [λ≤255nm; unpolarized; at 0°; at 45°]: Unpolarized; R≤1.0 % at 0 °, R≤1.5 % at 45 °

Anti-reflective coating can reduce the intensity of reflected light, thereby increasing the intensity of transmitted light and making optical system imaging clearer. It has a wide range of applications in LED displays, touch screens, LCD projection systems, instrument windows, fingerprint analyzer windows, monitor protective lenses, antique mirror frame windows, high-end watch windows, eyeglass lenses, and screen-printed optical glass products.

Prism Non-Polarizing Beamsplitter (UV / VIS / NIR) - Angle of Incidence: 45º Prism Non-Polarizing Beamsplitter (UV / VIS / NIR) - Reflectance (400 nm – 2μm) (R; R s; R p): 10 %≤R≤90 %±5 % ;| R s – R p | ≤5 % Plate Non-Polarizing Beamsplitter (UV / VIS / NIR) - Angle of Incidence: 45º

Boxin can customize various depolarizing coatings according to customer requirements. These include prism depolarizing beam splitter coatings (UV / VIS / NIR), plate depolarizing beam splitter coatings (UV / VIS / NIR), prism broadband depolarizing beam splitter coatings (VIS / NIR), and plate depolarizing beam splitter coatings (IR). It has a wide range of applications in interferometers and various imaging instruments.
