Polarizing film
A polarizing film refers to a type of optical thin film used to generate polarized light or suppress the polarization effect of thin films. It has a wide range of applications in optical systems, optical instruments, and laser systems.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Prism Polarizing Beamsplitter Coating (UV) - Angle of Incidence | 45º |
| Prism Polarizing Beamsplitter Coating (UV) - Reflectance (Rs) | Rs > 99.5 % |
| Prism Polarizing Beamsplitter Coating (UV) - Transmittance (Tp) | Tp > 95 % |
| Prism Polarizing Beamsplitter Coating (UV) - Extinction Ratio (Tp / Ts) | Tp / Ts > 200:1 |
| Prism Polarizing Beamsplitter Coating (VIS / NIR) - Angle of Incidence | 45º |
| Prism Polarizing Beamsplitter Coating (VIS / NIR) - Reflectance (Rs) | Rs ≥ 99.9 % |
| Prism Polarizing Beamsplitter Coating (VIS / NIR) - Transmittance (Tp) | Tp ≥ 95 % |
| Prism Polarizing Beamsplitter Coating (VIS / NIR) - Extinction Ratio (Tp / Ts) | Tp / Ts ≥1000:1 |
| Prism Broadband Polarizing Beamsplitter Coating (VIS / NIR) - Angle of Incidence | 45º |
| Prism Broadband Polarizing Beamsplitter Coating (VIS / NIR) - Reflectance (Rs) | Rs ≥ 99.5 % |
| Prism Broadband Polarizing Beamsplitter Coating (VIS / NIR) - Transmittance (Tp) | Tp ≥ 95 % |
| Prism Broadband Polarizing Beamsplitter Coating (VIS / NIR) - Extinction Ratio (Tp / Ts) | Tp / Ts ≥200:1 |
| Plate Polarizing Beamsplitter Coating (UV) - Angle of Incidence | Brewster's Angle |
| Plate Polarizing Beamsplitter Coating (UV) - Reflectance (Rs) | Rs ≥ 99 % |
| Plate Polarizing Beamsplitter Coating (UV) - Transmittance (Tp) | Tp ≥ 93 % |
| Plate Polarizing Beamsplitter Coating (UV) - Extinction Ratio (Tp / Ts) | Tp / Ts ≥100:1 |
| Plate Polarizing Beamsplitter Coating (VIS / NIR) - Angle of Incidence | Brewster's Angle |
| Plate Polarizing Beamsplitter Coating (VIS / NIR) - Reflectance (Rs) | Rs ≥ 99 % |
| Plate Polarizing Beamsplitter (VIS / NIR) - Transmittance (Tp) | Tp ≥ 95 % |
| Plate Polarizing Beamsplitter (VIS / NIR) - Extinction Ratio (Tp / Ts) | Tp / Ts ≥100:1 |
| Plate Polarizing Beamsplitter (IR) - Angle of Incidence | Brewster's Angle |
| Plate Polarizing Beamsplitter (IR) - Reflectance (Rs) | Rs ≥ 99 % |
| Plate Polarizing Beamsplitter (IR) - Transmittance (Tp) | Tp ≥ 90 % |
| Plate Polarizing Beamsplitter (IR) - Extinction Ratio (Tp / Ts) | Tp / Ts ≥100:1 |
