iChrome CLE
The iChrome CLE is a compact and efficient four-color laser engine designed for applications requiring high precision and stability. It integrates four wavelengths in a single box, offering excellent image contrast and lifetime with AOM/AOTF-free diode design.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength 405nm | ±4nm |
| Wavelength 488nm | ±4nm |
| Wavelength 561nm | ±2nm |
| Wavelength 640nm | +3/-5nm |
| Center Wavelength Range CLE 405nm | ±4nm |
| Center Wavelength Range CLE 488nm | ±4nm |
| Center Wavelength Range CLE 561nm | ±2nm |
| Center Wavelength Range CLE 640nm | +3/-5nm |
| Fiber Coupled CW Output Power CLE-30 405nm | 40mW |
| Fiber Coupled CW Output Power CLE-30 488nm | 40mW |
| Fiber Coupled CW Output Power CLE-30 561nm | 40mW |
| Fiber Coupled CW Output Power CLE-30 640nm | 50mW |
| Fiber Coupled CW Output Power CLE-50 405nm | 50mW |
| Fiber Coupled CW Output Power CLE-50 488nm | 50mW |
| Fiber Coupled CW Output Power CLE-50 561nm | 50mW |
| Fiber Coupled CW Output Power CLE-50 640nm | 50mW |
| Fiber Coupled CW Output Power CLE-80 405nm | 50mW |
| Fiber Coupled CW Output Power CLE-80 488nm | 80mW |
| Fiber Coupled CW Output Power CLE-80 561nm | 50mW |
| Fiber Coupled CW Output Power CLE-80 640nm | 80mW |
| Power Stability | ±2% (drift over 8h @ room temperature ±3°C) |
| RMS Noise (10Hz-10MHz) 405nm | <0.5% |
| RMS Noise (10Hz-10MHz) 488nm | <0.5% |
| RMS Noise (10Hz-10MHz) 561nm | <1% |
| RMS Noise (10Hz-10MHz) 640nm | <0.5% |
| Beam Quality M² | <1.1 |
| Ellipticity | <10% |
| Polarization Ratio (typ.) | >100:1, linear |
| Fiber Output Connector | FC/AFC (8° angled) as standard, others like FC/PC, FC/APC, FCP8 or SC on request |
| Fiber Cable Length (max.) | 2m |
| Fiber Type | Single-mode, polarization maintaining |
| Fiber Numerical Aperture (5%) 405nm | 0.080 |
| Fiber Numerical Aperture (5%) 488nm | 0.076 |
| Fiber Numerical Aperture (5%) 561nm | 0.071 |
| Fiber Numerical Aperture (5%) 640nm | 0.066 |
| Operating Ambient Temperature Range | 15..35°C |
| Dimensions Laser Head CLE, CLE-30 | 110x205x250mm³ |
| Dimensions Laser Head CLE-50, CLE-80 | 137x205x250mm³ |
