DFB & DBR Laser Diodes
DFB and DBR laser diodes are single-frequency lasers with a frequency-selective structure integrated into the laser chip, ensuring stable and precise operation. They are ideal for high-resolution spectroscopy and applications requiring mode-hop-free tuning.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range (nm) | 633-1572 |
| Maximum Output Power (mW) | 40-140 |
| Thermal Tuning Coefficient (nm/K) | 0.06-0.12 |
| Linewidth (kHz) | 30-2000 |
| Laser Check | Available for selected models |
| Package Type | TO-3, Butterfly, Pigtail |
| Tuning Range (GHz) | 100 |
| Central Wavelength Tolerance (nm) | ±1 |
| Operating Temperature Range (°C) | -10 to +40 |
| Modulation Frequency Range (Hz) | 0.1-100 |
| Modulation Current Amplitude (mA) | 10-59 |
| Thermal Tuning Rate (GHz/mA) | 1.2-0.7 |
| Spectral Resolution (nm) | 0.05 |
| Spectral Noise Density (dB) | -50 to 0 |
