Micro-channel Water-cooled Horizontal Stack High-power Semiconductor Laser
The BWT micro-channel water-cooled horizontal stack high-power semiconductor laser adopts advanced micro-channel water-cooling technology for superior heat dissipation and stable high-power output. Available in 808nm and 940nm center wavelengths with CW or QCW operation modes, it delivers 60W per bar in CW mode and up to 500W per bar in QCW mode, configurable with 1 to 4 laser bars. Featuring low smile effect, high reliability, narrow spectral width (<5nm) and electro-optical conversion efficiency above 50%, it is widely used as a pump source and in scientific research, medical and material processing applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Operation Mode E2Y-808.3-240C-1x4 | CW |
| Operation Mode E2Y-808.3-2000Q-1x4 | QCW |
| Operation Mode E2Y-940.3-2000Q-1x4 | QCW |
| Center Wavelength (nm) E2Y-808.3-240C-1x4 | 808±3nm |
| Center Wavelength (nm) E2Y-808.3-2000Q-1x4 | 808±3nm |
| Center Wavelength (nm) E2Y-940.3-2000Q-1x4 | 940±3nm |
| Output Power per Bar (W) E2Y-808.3-240C-1x4 | 60W |
| Output Power per Bar (W) E2Y-808.3-2000Q-1x4 | 500W |
| Output Power per Bar (W) E2Y-940.3-2000Q-1x4 | 500W |
| Number of Bars (pcs) | 1~4 |
| Spectral Width FWHM (nm) | <5nm |
| Fast Axis Divergence (95% Energy) (deg) | 60-70° |
| Fast Axis Divergence after FAC (90% Energy) (mrad) | ≤8mrad |
| Slow Axis Divergence (95% Energy) (deg) | 8-12° |
| Threshold Current (A) E2Y-808.3-240C-1x4 | ≤20A |
| Threshold Current (A) E2Y-808.3-2000Q-1x4 | ≤40A |
| Threshold Current (A) E2Y-940.3-2000Q-1x4 | ≤40A |
| Operating Current (A) E2Y-808.3-240C-1x4 | ≤70A |
| Operating Current (A) E2Y-808.3-2000Q-1x4 | ≤480A |
| Operating Current (A) E2Y-940.3-2000Q-1x4 | ≤480A |
| Operating Voltage per Bar (V/bar) | ≤2 |
| Frequency (HZ) E2Y-808.3-2000Q-1x4 | 200-1000 |
| Frequency (HZ) E2Y-940.3-2000Q-1x4 | 200-1000 |
| Duty Cycle (%) E2Y-808.3-2000Q-1x4 | ≤10% |
| Duty Cycle (%) E2Y-940.3-2000Q-1x4 | ≤10% |
| Slope Efficiency (W/A) | ≥4.4W/A |
| Electro-Optical Conversion Efficiency (%) | ≥50% |
| Water pressure (bar) | <5bar |
| Water Flow Rate (L/min/bar) | <0.33 |
| Deionized Water Quality | 2.5±0.5μS/cm,pH-value 5.5-8,filter≤5μm |
