EB-MCP-V#-100-####-0808-10
The EB-MCP-V#-100-####-0808-10 is a high-performance laser diode module designed for industrial and biomedical applications. It offers excellent reliability, efficiency, and long lifetime, making it ideal for demanding environments.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength | 808nm |
| Wavelength Tolerance | ±10nm |
| Output Power | 100W |
| Number of Bars | 2-60 |
| Spectral Width (FWHM) | 8nm |
| Operating Mode | CW |
| Fast-axis Divergence | 65Deg |
| Slow-axis Divergence | 10Deg |
| Wavelength Temperature Coefficient | 0.28nm/°C |
| Power Conversion Efficiency | 50% |
| Slope Efficiency/Bar | 1.1W/A |
| Threshold Current | 26A |
| Operating Current | 105A |
| Operating Voltage/Bar | 2/bar |
| Operating Temperature | 15~35°C |
| Bar/Water Velocity/Bar | 0.3-0.5l/m |
| Storage Temperature | 0-55°C |
| Entrance Maximum Pressure | 55psi |
| Water Type | DI Water |
| Resistivity of Deionized (DI) Water | 200-500kΩ·cm |
| Pure Water Filter Particles | 20μm |
