Optical Window

Thickness differential: ±0.1mm

Product Series Quartz Optical Window (Fused Silica Windows);

N-BK7, UV Quartz, Material High-Precision Shape Optical Window;

Materials: k9 Melting stone / Imported stone / sapphire/Caf2 ♪ Melted stone ♪: k9 Melting stone / Imported stone / sapphire/Caf2 Surface mass: 40/20

The main function of the protective lenses is to protect the focus lenses from being splattered by dust and high-temperature splatters; and to ensure the accuracy of the processing by periodically replacing the protective lenses. The lens will be effective in increasing the pass rate of the lenses when they are coated with a high damage threshold; reducing energy losses; and improving the quality of the processed product. Extensive applications in laser processing such as lasers, laser cutters, laser welders, fibre cutters, handheld welders, etc

Materials: k9 Melting Rock / Imported Rock Face: λ/4@632.8mm Surface mass: 40/20

Wedges, wedge lenses are an optical component of a plane and another plane with a certain angle; they are used mainly in the optical field to control beam deviation; they have a relatively small inclination; they can make light tend to one side thicker. Decline

Hard-quality protective film; customized to client requirements
