High-performance silicon wafers
Okmetic specializes in advanced silicon wafers tailored for MEMS, RF, and power devices, offering high resistivity and customizable solutions.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wafer Size | 150-200mm |
| Resistivity Range | <0.001Ohm-cm to >10kOhm-cm |
| Device Layer Thickness | 1μm to >200μm |
| Buried Oxide Layer Thickness | 0.3μm to 4μm |
| Handle Wafer Thickness | 300μm to 950μm |
| Crystal Material | MCz, A-MCz |
| Wafer Type | SOI, C-SOI, E-SOI, Patterned, DSP, SSP, TSV |
| Customization Options | Dopants |
| Customization Options | orientations |
| Customization Options | resistivity levels |
Applications
Key Features
Datasheet
Supplier Information
Related Products
-
High-performance silicon wafers
Semiconductor Manufacturing Equipment
Ybsemi-Solution
Wafer Size: 150-200mm Resistivity Range: <0.001Ωcm to >10kΩcm Device Layer Thickness: 1μm to >200μm
Okmetic specializes in advanced silicon wafers tailored for MEMS, RF, and power devices, offering high resistivity and customizable solutions.
-
Wafer Scribing Machine
Semiconductor Manufacturing Equipment
Uwlaser
: Parameter value : ≤ 10μm (factory parallelism/flatness/verticality/right angle) : ±0.5μm
-
Wafer Cleaving System
Semiconductor Manufacturing Equipment
Uwlaser
: 2 inch-6 inch wafer : About 2 dollars/s : ±3μm
-
Laser Wafer Modification Cutting System
Semiconductor Manufacturing Equipment
Uwlaser
: 4inch, 6inch, 8inch, 12inch (optional) : Maximum 1000mm/s : wafer Frame
-
Fully Automatic Optoelectronic Device Die Bonding and Assembly System
Semiconductor Manufacturing Equipment
Ybsemi-Solution
Equipment Type: Fully automatic die bonding and assembly system Configuration: Dual-station enclosed chamber with front double doors Observation Window: Large transparent safety windows on processing chamber
This is a fully automatic high-precision die bonding and assembly system designed for optoelectronic device manufacturing. Based on the product image, the equipment features a dual-station enclosed processing chamber with large observation windows, dual HMI touchscreen control panels, multi-color tower status lights, and automated cassette/magazine loading for substrates or wafers. The system integrates precision motion control, vision alignment, and automated material handling to achieve high-throughput, high-accuracy die attach, component placement, and packaging processes for photonic and semiconductor devices. The enclosed clean-room-compatible design with safety interlocks ensures process stability, particle control, and operator safety during continuous production.
