AQ2200-312 Attenuator Module
The AQ2200-312 is a single-channel attenuator module designed for precise optical signal attenuation in various optical testing scenarios.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Insertion Loss (dB) | ≤1.0dBtyp. |
| Attenuation Range (dB) | 0-60dB |
| Attenuation Resolution (dB) | 0.01dB |
| Maximum Input Power (dBm) | 10dBm |
| Fiber Type | SMF(10/125μm), MMF50/125μm, MMF62.5/125μm |
Applications
Key Features
Datasheet
