OSICS ATN
The OSICS ATN module integrates industry-standard attenuator components, combining a 60 dB attenuation range with the power to operate throughout a large wavelength range.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range (nm) SMF models | 1250 to 1650 |
| Wavelength Range (nm) PMF models | 1440 to 1650, 1250 to 1510 |
| Attenuation Range | IL to 60 dB (typical) |
| Calibrated Range SMF models | Up to 40 dB at 1310 nm and 1550 nm |
| Calibrated Range PMF models | Up to 40 dB at 1550 nm, 1625 nm, 1310 nm |
| Attenuation Accuracy (typical) | ±0.3 dB |
| Insertion Loss (IL) | <2 dB (1 dB typical) |
| Attenuation Setting and Display Resolution | 0.1 dB (display resolution: 0.01 dB) |
| Polarization Dependent Loss | <0.1 dB |
| PER | N/A, ≥18 dB |
| Return Loss | ≥50 dB |
| Maximum Input Power | 2 W (33 dBm) |
| Optical Connectors | FC/APC narrow key |
