TruAccelerate
Custom designed solid-state power amplifier at various power levels and frequencies.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Rated Power | 5000W |
| Nominal Load Impedance | 50Ω |
| Output Frequency | 80.5MHz / 161MHz / 162.5MHz / 322MHz / 500MHz / 644MHz |
| Line Voltage | 3/PE AC 200–230V or 3/N/PE 400–480V |
| Line Frequency | 50/60Hz±3Hz |
| Line Input Power | 8.4kVA |
| Power Factor | >0.9 |
| Analog/Digital Interfaces | Yes |
| RS232/RS485 Interfaces | Yes |
| Ethernet Interface | Yes |
| CAN-FD Interface | Yes (internal) |
| IP Protection Class | 21 |
| Dimensions (W×H×D) | 483mm×177mm×660mm |
| Maximum Water Pressure | 10bar |
| Minimum Pressure Difference | 3bar |
| Minimum Flow Rate | 10–18l/min (depending on VSWR output) |
| Coolant Temperature | 25°C–35°C |
| Overall Efficiency | >60% (depending on frequency and CW/Pulse) |
| Certificates/Standards | RoHS | CE | NRTL | FCC Part 18 | EN 61000-3-12,-3 | EN 61000-4-2,3,4,5,6,8,11 | EN 61010-1 | EN V50204 | EN 55024 | EN 55011 | Group 2 Class A |
| Outside Temperature | 15°C–40°C |
| Humidity | 5%–95% (not condensing) |
