Photonics Source provides 1237 products. Download datasheets, request quotes, and compare function, price, and availability.
-
FC Expansion Connector
Operating Wavelength: 780,795,850,980,1060,1310,1550nm Insertion Loss: <0.5dB (typical value 0.3) Extinction Ratio: ≥25dB Return Loss: ≥50dB Maximum Laser Power: 500mW (high-power available) -
Polarization Beam Splitter/Combiner (PBS/PBC) 1x2
Center Wavelength (nm): 780/808/850 Operating Bandwidth (nm): ±20 Insertion Loss (dB): 0.8 (typical), 1.0 (maximum) Extinction Ratio Min. (dB): 18 Directivity Min. (dB): 50 -
High Power Cladding Power Stripper (CPS)
Laser Wavelength (nm): 700~2000 Polarization: Random or fixed Operating Mode: Continuous Signal Loss (dB): 0.05 (typical) Fiber Length (m): 1.0 -
Manual Fiber Polarization Controller (MFPC-56)
Fiber Patch Cable: AFC-R-780HP-5, AFC-Q-HI1060-5, UFC-Q-SMF28-5 Operating Wavelength Range: 780-970nm, 980-1650nm, 1260-1625nm Design Wavelength: 780nm and 850nm, 980nm and 1064nm, 1310nm and 1550nm Mode Field Diameter: 5.0±0.5μm@850nm, 5.9±0.3μm@980nm, 9.2±0.4μm@1310nm Cladding Diameter: 125±1μm -
Polarization Maintaining Collimator
Central Wavelength (nm): 532, 630/670, 780/830/850, 980/1030/1064, 1310/1480/1550, 1950/2000/2050 Bandwidth (nm): ±10, ±30 Working Distance (mm): 5~100 Spot Size (mm): ≤0.6 Insertion Loss (dB): 1.2, 0.8, 0.4, 0.3, 0.4 -
1×N Polarization Optical Switch
Operating Wavelength (nm): 532,650,780,850,980,1064,1260~1660 Measured Wavelength (nm): 532,650,780,850,980,1064,1310,1490,1550,1650 Insertion Loss (dB): 0.6 (typical), 1.2 (max) Return Loss (dB): ≥55 Crosstalk (dB): ≥80 -
Fiber Optic Mirror
Center Wavelength (nm) 525/633: ±20 Center Wavelength (nm) 780/850: ±40 Center Wavelength (nm) 980/1030/1064: ±40 Center Wavelength (nm) 1310/1480/1550: ±50 Center Wavelength (nm) 1950/2000/2050: ±50 -
Polarization-Maintaining Fiber Mirror
Center Wavelength (nm) 525/633: ±10 Center Wavelength (nm) 780/850: ±20 Center Wavelength (nm) 980/1030/1064: ±30 Center Wavelength (nm) 1310: ±30 Center Wavelength (nm) 1480/1550: ±30 -
520nm Three-Port Polarization-Maintaining Optical Circulator
Center Wavelength (nm): 520 Operating Wavelength Range (nm): ±5 Ports and Operating Mode: 3 ports (Port 1→2, 2→3) Isolation (dB): ≥20 Insertion Loss (dB): ≤1.5 -
Non-Magnetic Polarization Maintaining Fiber Pigtail
Test Wavelength (nm) 520nm: ±20 Test Wavelength (nm) 850nm: ±20 Output Beam (mm) 520nm: 1.3±0.1 Output Beam (mm) 850nm: 1.3±0.1 Working Distance (mm): 0~150 -
Inline Polarizer
Center Wavelength (nm) 460: 460 Center Wavelength (nm) 630: 630 Operating Wavelength Range (nm) 460: ±5 Operating Wavelength Range (nm) 630: ±5 Insertion Loss (dB) 460: ≤1.8 -
Fiber Retroreflector
Fiber Type SM600: SM600 Wavelength Range SM600: 630~780nm Mode Field Diameter SM600: 3.6~5.3±0.3μm Insertion Loss (dB) SM600: ≤4 Cladding Diameter SM600: 125±1.0μm -
Extruded Polarization Controller
Operating Wavelength (nm): 405~1700 Insertion Loss (dB): <0.05 Extinction Ratio (dB): >40 Return Loss (dB): ≥65 Operating Temperature (°C): -40~+85 -
Multimode Fiber Rotary Connector Jumper
Model RJPF2: RJPF2 Model RJPF4: RJPF4 Model RJPS4: RJPS4 Connector Type RJPF2: FC/PC Connector Type RJPF4: FC/PC -
350–5000nm FiberPort Collimator/Combiner
Model FP-C: FC/PC Model FPP-C: FC/PC Model FPA-C: FC/APC Model FPS-C: SMA Model FP-M: FC/PC -
Mechanical Optical Switch 2x2
Operating Wavelength (nm): 1260~1620 Insertion Loss (dB): ≤1.0 Crosstalk (dB): ≥55 Return Loss (dB): ≥50 Polarization Dependent Loss (dB): ≤0.05 -
2D Fiber Arrays
Arrangement Method: Linear, square, circular, polygonal, fan-shaped, dense and scattered, customizable Minimum Arrangement Period (μm): 70 Vibration Fiber Diameter (μm): 50 Fiber Type: Various types/multi-mode, single-mode, and double-cladding fibers optional Peripheral Deviation (μm): ±1 -
Manual Fiber Polarization Controller
Model No.: MFPC-27 Number of Paddles: 3 Loop Diameter: 1.06" (27mm) Paddle Rotation: ±117.5° Footprint (L×W): 184.5mm×25mm -
200–5000nm Antiresonant Hollow Core Fiber
Central Operating Wavelength Range (nm): 200–5000 Central Operating Wavelength Typical Loss (dB/m): 0.001–0.1 Transmission Bandwidth (THz): ＞200 Mode Field Diameter (μm): 18–120 -
19-Core Photonic Bandgap Fiber
Central Operating Wavelength Range (nm): 500–2000 Central Operating Wavelength Typical Loss (dB/m): 0.005–0.3 Transmission Bandwidth (THz): <70 Mode Field Diameter (μm): 6–20
