Intelligent Process Monitor Intelligent process monitoring system IPM3.0
The IPM3.0 system is a real-time online quality-monitoring system integrating advanced optical sensors, high-speed data-processing modules, and artificial-intelligence algorithms.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| 采样频率 | Up to 200 kHz |
| 传感器/通道 | 3 / 4 |
| 调试/校准 | Precalibrated |
| 高灵敏度(激光功率) | > 10W to > 30kW |
| 可检测缺陷 | Incomplete welds, burn-through, changes in penetration depth, voids, etc. |
| 交互 | TCP/IP or I/O |
| 空间尺寸 | 140 mm × 110 mm × 70 mm |
| 整体功耗 | 600W |
| 外部接口 | RJ45 and power-supply cable |
| 软 Items系统支持 | Windows / Linux dual operating systems |
