100W Nanosecond Infrared Fiber Laser
Save to Favorites
Specifications
| Parameter | Value |
|---|---|
| M² Beam quality | ＜1.4 |
| Average Output Power | ＞100 |
| Power adjustment Range | 0~100 % |
| Max Pulse energy | 2 mJ |
| Frequency Adjustment range | 1-4000 kHz |
| Pulse width | 3-500 ns |
| Output Power Instability | <5 % |
| Center wavelength | 1064 nm |
| Spectral width @3dB | <15 nm |
| Polarization direction | Any |
| High-Reflection Resistance Status | Yes |
| Beam diameter | 7.0±0.5 mm |
| Output Armored Cable Length | 3 m |
| Red Aiming Beam Function | Yes |
| Cooling method | Air cooling |
| Supply voltage | 24 V |
| Max Power consumption | <450 W |
| Supply current | >18 A |
| Recommended Power Supply Power | ≥450 W |
| Operating temperature Range | 0~40 ℃ |
| Storage temperature Range | -10~60 ℃ |
| Laser Dimensions | 256 mm × 219 mm × 100 mm |
| Package dimensions | 615 mm × 465 mm × 215 mm |
| Weight | Net: 6, Gross: 8.2 |
