Plano optical components
Plano optical components are flat elements fabricated from various optical glasses, crystals, and infrared materials.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Material | Colorless optical glass, colored optical glass, laser crystals, fused silica, radiation-resistant glass, ultraviolet and infrared materials, fiber optical glass, acousto-optic glass, magneto-optic glass, and photochromic glass, e.g.: SiO₂, CaF₂, BaF₂, ZnSe, ZnS, Ge, Si, Al₂O₃, etc. |
| Outer dimension range (Φ) [Non-circular machining size = 1200 mm] | Φ1.8~Φ1200 (non-circular machining size: 1200 mm) |
| Outline Tolerance | ±0.005 ~±0.2 mm |
| Thickness Tolerance | ±0.01 ~±0.2 mm |
| Surface Quality | 10/5~80/50 |
| Surface accuracy [Aperture = Φ100 mm] | λ/20~λ/Φ100 mm |
| Parallelism | 10 ″~5 ′ |
| Coating [Customizable] | Customized upon request (see Boxin coating process types and film layer introduction for details) |
