capaNCDT
capaNCDT is a high-precision capacitive displacement sensor system designed for industrial applications. It offers unparalleled accuracy and stability, making it suitable for various measurement tasks.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Measuring Range CS005 | 0.05mm |
| Measuring Range CS02 | 0.2mm |
| Measuring Range CS05 | 0.5mm |
| Measuring Range CS08 | 0.8mm |
| Linearity CS005 | ≤±0.15μm |
| Linearity CS02 | ≤±0.4μm |
| Linearity CS05 | ≤±0.15μm |
| Linearity CS08 | ≤±0.4μm |
| Resolution Static 2Hz CS005 | 0.0375nm |
| Resolution Static 2Hz CS02 | 0.15nm |
| Resolution Static 2Hz CS05 | 0.375nm |
| Resolution Static 2Hz CS08 | 0.6nm |
| Temperature Stability CS005 | ≤0.3%FSO |
| Temperature Stability CS02 | ≤0.2%FSO |
| Temperature Stability CS05 | ≤0.3%FSO |
| Temperature Stability CS08 | ≤0.2%FSO |
| Operating Temperature | -50°C to +200°C |
| Storage Temperature | -50°C to +200°C |
| Dimensions CS005 | Ø6×12mm |
| Dimensions CS02 | Ø6×12mm |
| Dimensions CS05 | Ø8×12mm |
| Dimensions CS08 | Ø10×15mm |
| Material | NiFe (magnetic) |
| Installation | Type C |
| Weight CS005 | 2g |
| Weight CS02 | 2g |
| Weight CS05 | 4g |
| Weight CS08 | 7g |
