400-700nm全介质反射镜
This product is a dielectric mirror designed for the wavelength range of 400-700nm, offering high reflectivity and excellent optical performance.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range | 400-700nm |
| Reflectivity | ≥99% |
| Substrate Material | Optical glass |
| Dimensions | Customizable |
| Surface Quality | 40/20 |
| Incident Angle | 0-45° |
Applications
Key Features
Datasheet
Supplier Information
