Flexible Hose Clamp
The INFICON ISO-KF clamp is manufactured according to ISO 2861/1, DIN 28403, and Pneurop 6606 standards. It is a high-quality component designed for all vacuum and high vacuum applications, ensuring a low leak rate of 1 × 10^-9 mbar l/s.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Type | DN 16 ISO-KF, DN 25 ISO-KF, DN 40 ISO-KF |
| Specification A | 13, 19, 26 |
| Specification B | 32, 44, 76 |
| Material | Stainless steel 430/- |
