Flexible Hose Coupling with Clamp
The INFICON ISO-KF coupling is manufactured according to ISO 2861/1, DIN 28403, and Pneuro 6606 standards. It is a high-quality standard component designed for all vacuum and high vacuum applications, ensuring a low leak rate of less than 1 × 10⁻⁹ mbar l/s.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Specification A DN 16 ISO-KF | 58 |
| Specification A DN 25 ISO-KF | 60 |
| Specification A DN 40 ISO-KF | 64 |
| Specification B DN 16 ISO-KF | 7 |
| Specification B DN 25 ISO-KF | 9 |
| Specification B DN 40 ISO-KF | 13 |
| Specification C DN 16 ISO-KF | 14 |
| Specification C DN 25 ISO-KF | 16 |
| Specification C DN 40 ISO-KF | 20 |
| Specification D DN 16 ISO-KF | 16 |
| Specification D DN 25 ISO-KF | 25 |
| Specification D DN 40 ISO-KF | 40 |
| Specification E DN 16 ISO-KF | 44 |
| Specification E DN 25 ISO-KF | 50 |
| Specification E DN 40 ISO-KF | 68 |
| Sleeve | CR |
| Hose Clamp DN 16 ISO-KF | Stainless steel 430/- |
| Hose Clamp DN 25 ISO-KF | Stainless steel 430/- |
| Hose Clamp DN 40 ISO-KF | Stainless steel 430/- |
| Internal Pressure DN 16 ISO-KF | Max.1bar |
| Internal Pressure DN 25 ISO-KF | Max.1bar |
| Internal Pressure DN 40 ISO-KF | Max.1bar |
