739874 AC Adapter
The 739874 AC Adapter is designed for specialized instruments, ensuring safe and efficient power supply for Yokogawa devices.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Rated Supply Voltage | 100VAC to 240VAC |
| Rated frequency range | 50Hz to 60Hz |
| Allowable supply voltage range | 90VAC to 264VAC |
| Allowable frequency range | 48Hz to 62Hz |
| Maximum Input Current | 0.6A |
| Maximum output current | 3.0A |
| Operating Environment Temperature | 0°C to 40°C |
| Operating Environment Humidity | 20% to 85%RH (no condensation) |
| Storage Environment Temperature | -20°C to 60°C |
| Storage Environment Humidity | 5% to 95%RH (no condensation) |
| External Dimensions | 98.5mm×59.5mm×31.2mm (excluding the cord) |
| Weight | Approx. 250g |
| Safety Standards | IEC/EN/UL 60950-1, CAN/CSA-C22.2, No.60950-1, AS/NZS 60950-1 |
| EMC Standards | EN61326-1 Class B, EN55011 Class B, AS/NZS CISPR11 Class B |
| Environmental standards | RoHS Directive compliant |
