AQ6361 Optical Spectrum Analyzer
The AQ6361 is a high-speed optical spectrum analyzer designed for evaluating optical components and systems in modern production environments. It features a compact design, faster measurement speed, and high optical performance, ensuring precision and reliability for customers.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range SW Model | 1200nm-1700nm |
| Wavelength Range EW Model | 700nm-1700nm |
| Wavelength Range SW1 | 1nm-500nm,0nm |
| Wavelength Range EW1 | 0.1nm-1000nm,0nm |
| Wavelength Accuracy SW Model | ±0.02nm(1520-1580nm,1580-1620nm) |
| Wavelength Accuracy EW Model | ±0.04nm(1450-1520nm,1520-1580nm,1580-1620nm) |
| Wavelength Accuracy | ±0.01nm(1450-1620nm) |
| Wavelength Resolution | 0.03,0.05,0.1,0.2,0.5,1,2nm |
| Power Range | +20~-80dBm |
| Power Accuracy | ±0.2dB |
| Dynamic Range | 73dB |
| Spectral Bandwidth | 50dB(±0.2nm),37dB(±0.1nm) |
| Sweep Time TRAD Mode | 0.2s,0.5s,1s,2.5s,10s |
| Sweep Time RAPID Mode | 0.14s |
| Data Storage | CSV |
| Data Storage | BMP |
| Data Storage | PNG |
| Data Storage | JPEG |
| Dimensions | 213mm(W)x177mm(H)x459mm(D) |
| Weight | 11kg |
| Power Requirements | 100-240VAC,50/60Hz,100VA |
| Environmental Conditions | Operating temperature: +5°C to +35°C, Storage temperature: -10°C to +50°C, Humidity: 20%-80% RH |
