AQ2200-312 Attenuator Module
The AQ2200-312 is a single-channel attenuator module designed for precise optical signal attenuation in optical communication systems.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Low Insertion Loss | ≤1.0dB |
| Attenuation Resolution | 0.01dB |
| Maximum Input Power | +10dBm |
| Applicable Fiber | SMF(10/125μm), MMF(50/125μm, 62.5/125μm) |
Applications
Key Features
Datasheet
