DZO_IR3520A
The DZO_IR3520A is a high-performance infrared lens designed for precision imaging applications. It features advanced optical design and robust construction, ensuring reliable performance in demanding environments.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Sensor Type | 24.0mm×18.0mm | Φ30.0mm |
| Focal Length | 35.00mm | At infinity |
| Mechanical Back Focal Length | 12.00mm | M42 |
| Aperture | F2.0-F22.0 | At infinity |
| Angle of View | 20.67° | Y=15mm, 21.69° | Y=12mm, 23.20° | Y=9mm |
| Optical Distortion | -0.66% | Y=15mm, -0.59% | Y=12mm, -0.50% | Y=9mm |
| Relative Illumination | 70.65% | Y=15mm, 76.84% | Y=12mm, 75.07% | Y=9mm |
| Working Distance | 160mm, 300mm, Inf |
| Operating Temperature | -20°C~+60°C |
| Optical magnification | 0.0383X | 900mm, 0.0405X | 850mm, 0.0430X | 800mm, 0.0458X | 750mm, 0.0490X | 700mm, 0.0526X | 650mm, 0.0569X | 600mm, 0.0619X | 550mm, 0.0679X | 500mm, 0.0751X | 450mm, 0.0841X | 400mm, 0.0956X | 350mm, 0.1108X | 300mm, 0.1318X | 250mm, 0.1629X | 200mm, 0.2013X | 160mm |
