4×25G 100G Muxponder Card
The product is designed for multiplexing 4 channels of 25/28G optical signals into a single 100G optical signal or demultiplexing a 100G optical signal into 4 channels of 25/28G optical signals. Based on the principle of OEO, it adopts a transparent forwarding method for business data. It is suitable for long-distance transmission of 100G optical signals or multiplexing of 25G signals.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Access signal rate 25G port | 25.5-28.1Gbps |
| Access signal rate 100G port | 103-112Gbps |
| Signal mode | SM/MM |
| Optical transceiver slot numbers | SFP28×4,QSFP28×1 |
| Extinction Ratio | ≥6dB |
| SMSR | ＞30dB |
| Consumption | ＜20W |
Applications
Key Features
Datasheet
Supplier Information
