EyeSafe Delivery Fibers
Nufern has specifically engineered a unique range of single-mode 2μm beam delivery fibers for the long wavelength EyeSafe window from 1850-2200nm, available in both PM and non-PM versions. By applying extensive fiber manufacturing expertise, this family of fibers has excellent uniformity and high fatigue failure resistance. These fibers are aimed at emerging fiber applications for the 2μm wavelength, including medical, military/aerospace, and industrial fiber laser markets.
Specification Snapshot
Cutoff SM1950
1720±80nm
Cutoff PM1950
1720±80nm
Cladding Diameter SM1950
125.0±1.0μm
Cladding Diameter PM1950
125.0±1.0μm
Core Diameter SM1950
7.0μm
Core Diameter PM1950
7.0μm
Request a Quote
Download Datasheet
Chat
Overview
Nufern has specifically engineered a unique range of single-mode 2μm beam delivery fibers for the long wavelength EyeSafe window from 1850-2200nm, available in both PM and non-PM versions. By applying extensive fiber manufacturing expertise, this family of fibers has excellent uniformity and high fatigue failure resistance. These fibers are aimed at emerging fiber applications for the 2μm wavelength, including medical, military/aerospace, and industrial fiber laser markets.
Specifications
| Parameter | Value |
|---|---|
| Operating Wavelength SM1950 | 1850–2200nm |
| Operating Wavelength PM1950 | 1850–2200nm |
| Core NA SM1950 | 0.200 |
| Core NA PM1950 | 0.200 |
| Mode Field Diameter SM1950 | 8.0μm@1950nm |
| Mode Field Diameter PM1950 | 8.0μm@1950nm |
| Cutoff SM1950 | 1720±80nm |
| Cutoff PM1950 | 1720±80nm |
| Beat Length PM1950 | ≤2.5mm@1950nm |
| Birefringence PM1950 | nominal 3.5×10^-4 |
| Cladding Diameter SM1950 | 125.0±1.0μm |
| Cladding Diameter PM1950 | 125.0±1.0μm |
| Core Diameter SM1950 | 7.0μm |
| Core Diameter PM1950 | 7.0μm |
| Coating Diameter SM1950 | 245.0±15.0μm |
| Coating Diameter PM1950 | 245.0±15.0μm |
| Coating Concentricity SM1950 | <5.0μm |
| Coating Concentricity PM1950 | <5.0μm |
| Core/Clad Offset SM1950 | ≤0.50μm |
| Core/Clad Offset PM1950 | ≤0.50μm |
| Coating Material SM1950 | UV Cured |
| Coating Material SM1950 | Dual Acrylate |
| Coating Material PM1950 | UV Cured |
| Coating Material PM1950 | Dual Acrylate |
| Operating Temperature Range SM1950 | -40 to 85°C |
| Operating Temperature Range PM1950 | -40 to 85°C |
| Proof Test Level SM1950 | ≥100kpsi(0.7GN/m²) |
| Proof Test Level PM1950 | ≥100kpsi(0.7GN/m²) |
Applications
1. Pigtailed 2μm components 2. 2μm-fiber lasers/amplifiers 3. 2μm beam delivery
Key Features
1. Optimized for 2μm wavelengths — Higher performance 2. Low bend loss at 2μm — Tighter packaging 3. Tight tolerances — High product yield
