Visible Wavelength Select Cutoff Single-Mode Fibers

Visible Wavelength Select Cutoff Single-Mode Fibers

Supplier
Fibretop
Part Number
Visible Wavelength Select Cutoff Single-Mode Fibers
Category
Fiber Optics
Origin
China

Nufern's visible wavelength fibers are optimized for use from 400 to 900 nm. These high-performance fibers are designed for applications requiring generation of couplers, diode pig tails, and unique delivery needs. They feature greater proof test levels and tighter second mode cutoff tolerances than standard fibers, resulting in higher strength, increased component reliability, better production yields, and reduced costs for component manufacturers.

Specification Snapshot
Operating Wavelength 405-HP
400-550nm
Operating Wavelength 460-HP
450-600nm
Operating Wavelength 630-HP
600-770nm
Cladding Diameter
125.0±1.0μm
Core Diameter 405-HP
2.1μm
Core Diameter 460-HP
2.5μm
Request a Quote Download Datasheet Chat
Save to Favorites Save to Favorites

Overview

Nufern's visible wavelength fibers are optimized for use from 400 to 900 nm. These high-performance fibers are designed for applications requiring generation of couplers, diode pig tails, and unique delivery needs. They feature greater proof test levels and tighter second mode cutoff tolerances than standard fibers, resulting in higher strength, increased component reliability, better production yields, and reduced costs for component manufacturers.

Specifications

ParameterValue
Operating Wavelength 405-HP400-550nm
Operating Wavelength 460-HP450-600nm
Operating Wavelength 630-HP600-770nm
Mode Field Diameter (Gaussian) 405-HP3.5±0.5μm@515nm
Mode Field Diameter (Gaussian) 460-HP3.5±0.5μm@515nm
Mode Field Diameter (Gaussian) 630-HP4.0±0.5μm@630nm
Cutoff 405-HP≤30dB@515nm
Cutoff 460-HP≤12dB@630nm
Cutoff 630-HP≤12dB@630nm
Cladding Diameter125.0±1.0μm
Core Diameter 405-HP2.1μm
Core Diameter 460-HP2.5μm
Core Diameter 630-HP3.5μm
Coating Diameter245.0±15.0μm
Coating Concentricity≤5.0μm
Core/Clad Offset≤0.50μm
Coating MaterialUV Cured
Coating MaterialDual Acrylate
Operating Temperature Range-55 to 85°C
Short Term Bend Radius≥6mm
Long Term Bend Radius≥13mm
Prooftest Level≥200kpsi(1.4GN/m²)

Applications

1. Diode pig tails 2. Compact UV sources 3. RGB components 4. Couplers

Key Features

1. Superior fiber geometrical tolerances — Improved connectorization and coupling performance 2. Extremely tight second mode cutoff tolerance — Enhanced component reproducibility 3. Higher proof test level — Greater reliability for tight bend applications
