Polarization Maintaining Short Wavelength Fibers

Polarization Maintaining Short Wavelength Fibers

Supplier
Fibretop
Part Number
Polarization Maintaining Short Wavelength Fibers
Category
Fiber Optics
Origin
China

Coherent's industry-leading visible and short wavelength Polarization Maintaining fibers have superior waveguide, radiation, and mechanical properties enabling a large variety of critical applications in diverse markets. High consistency and extreme end-to-end control of optical properties provide particular advantage in spectrographic and frequency-sensitive applications. The intrinsically high level of radiation resistance allows this family to operate for extended periods of time on low earth orbits, near and deep space, and in applications where risk of exposure to man-made radiation is great.

Specification Snapshot
Operating Wavelength PM460-HP
460-700nm
Operating Wavelength PM630-HP
620-850nm
Operating Wavelength PM780-HP
770-1100nm
Cladding Diameter
125.0±1.0μm
Core Diameter
3.0μm
Coating Diameter
245.0±15.0μm
Request a Quote Download Datasheet Chat
Save to Favorites Save to Favorites

Overview

Coherent's industry-leading visible and short wavelength Polarization Maintaining fibers have superior waveguide, radiation, and mechanical properties enabling a large variety of critical applications in diverse markets. High consistency and extreme end-to-end control of optical properties provide particular advantage in spectrographic and frequency-sensitive applications. The intrinsically high level of radiation resistance allows this family to operate for extended periods of time on low earth orbits, near and deep space, and in applications where risk of exposure to man-made radiation is great.

Specifications

ParameterValue
Operating Wavelength PM460-HP460-700nm
Operating Wavelength PM630-HP620-850nm
Operating Wavelength PM780-HP770-1100nm
Mode Field Diameter (Gaussian) PM460-HP3.0±0.5μm@515nm
Mode Field Diameter (Gaussian) PM630-HP4.5±0.5μm@630nm
Mode Field Diameter (Gaussian) PM780-HP5.3±1.0μm@850nm
Cutoff PM460-HP≤30.0dB/km@488nm
Cutoff PM630-HP≤30.0dB/km@630nm
Cutoff PM780-HP≤40dB/km@850nm
Beat Length (nominal) PM460-HPnominal3.5×10^-4
Beat Length (nominal) PM630-HPnominal3.5×10^-4
Beat Length (nominal) PM780-HPnominal3.5×10^-4
Birefringence PM460-HPnominal3.5×10^-4
Birefringence PM630-HPnominal3.5×10^-4
Birefringence PM780-HPnominal3.5×10^-4
Cladding Diameter125.0±1.0μm
Core Diameter3.0μm
Coating Diameter245.0±15.0μm
Coating Concentricity<5.0μm
Core/Clad Offset<0.50μm
Coating MaterialAcrylate
Operating Temperature Range-40to85°C
Prooftest Level≥200kpsi(1.4GN/m²)

Applications

1. Laser pigtailed 2. Spectroscopy 3. Sensors 4. Bio-medical 5. Metrology

Key Features

1. Panda-style configuration—Superior performance, intrinsically good radiation performance 2. Tight specifications—Highly deterministic results, highest product yield 3. High Proof Test—Low risk of mechanical handling failure 4. High fatigue failure resistance—Longest service life
