TruHeat HF Series
TruHeat HF Series generators are designed for induction heating processes, offering compact size, high power density, and a broad frequency range. They are ideal for applications ranging from micro-device thermal treatment to highly automated heating processes.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Output Power | 5kW, 10kW |
| Output Frequency | 50kHz-450kHz at 35A, 50kHz-800kHz at 17.5A |
| Winding Ratio of the Output Transformer | 6:1-16:1 |
| Output Voltage | 250V, 520V |
| Output Current | 17.5-35A |
| Mains Power Consumption | 6.5kVA-12.5kVA |
| Mains Voltage | 3/PE AC 200/208V ±10%, 3/PE AC 400V ±10% |
| Mains Frequency | 50Hz/60Hz |
| Power Factor | 0.95 |
| Efficiency | 90% |
| Max. Water Pressure | 6bar |
| Min. Differential Pressure | 3bar |
| Water Flow Rate | 4.2l/min-9.5l/min |
| External Circuit | 3.6l/min |
| Max. Cooling Water Temperature | 35°C |
| Dimensions (W x H x D) HF Series 1000 | 211mm x 122mm x 500mm |
| Dimensions (W x H x D) HF Series 3000 | 483mm x 133mm x 662mm |
| Dimensions (W x H x D) HF Series 5000 | 555mm x 195mm x 700mm |
| Dimensions (W x H x D) External Circuit | 114mm x 186mm x 328mm |
| Weight HF Series 1000 | 16kg |
| Weight HF Series 3000 | 30kg |
| Weight HF Series 5000 | 41kg |
| Weight External Circuit | 12kg |
| Protection Class HF Series 1000 | IP30 |
| Protection Class HF Series 3000 | IP54 |
| Protection Class HF Series 5000 | IP54 |
| Protection Class External Circuit | IP54 |
| AD User Interface | 37-pin Sub-D |
| RS-232 | 9-pin Sub-D |
| CAN Bus | 5-pin mini-style connector |
| PROFIBUS | 9-pin Sub-D |
| Certification | CE |
