In-line Polarizer
the In-line Polarizer is designed to pass the light with the specified polarization,blocking the others.the function is tranform non-polarized light into linearly polarized light, for the high extincton ratio.It is also used to enhance the extinction ratio of the signals of precision measurement system, fiber sensor, high speed test instrumentations where the high extinction ratio prosper is required.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength [devices without connectors] | 1310 nm, 1480 nm or 1550 nm |
| Operating Wavelength Range [devices without connectors] | ± 50 nm |
| Typ. Insertion Loss at 23°C [devices without connectors；23°C；For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.] | 0.3 dB |
| Max. Insertion Loss at 23°C [devices without connectors；23°C；For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.] | 0.5 dB |
| Typ. Extinction ratio at 23°C [devices without connectors；23°C；For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.] | 30 dB |
| Min. Extinction ratio at 23°C [devices without connectors；23°C；For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.] | 28 dB |
| Min. Return loss [devices without connectors；For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower.] | 50 dB |
| Max. Optical Power (CW) [devices without connectors；CW] | 500 mW |
| Max. Tensile Load [devices without connectors] | 5 N |
| Fiber Type [devices without connectors] | PM Panda Fiber or SMF-28e |
| Operating Temperature [devices without connectors] | -5 to +70 °C |
| Storage Temperature [devices without connectors] | -40 to +85 °C |
