Polarizing beamsplitter prism

Polarizing beamsplitter prism

Supplier
Transoptics
Category
Polarization Optics
Origin
China

A polarizing beamsplitter prism is formed by cementing a pair of high-precision right-angle prisms. A polarizing beamsplitting dielectric coating is deposited on the hypotenuse of one of the prisms, and an anti-reflection coating is deposited on the outer surface. It can split incident unpolarized light into two beams of perpendicular linearly polarized light, in which the P-polarized light passes through completely, and the S-polarized light is reflected at 45 degrees, with the exit direction forming a 90-degree angle with the P-polarized light.

Request a Quote Download Datasheet
Save to Favorites Save to Favorites

Overview

A polarizing beamsplitter prism is formed by cementing a pair of high-precision right-angle prisms. A polarizing beamsplitting dielectric coating is deposited on the hypotenuse of one of the prisms, and an anti-reflection coating is deposited on the outer surface. It can split incident unpolarized light into two beams of perpendicular linearly polarized light, in which the P-polarized light passes through completely, and the S-polarized light is reflected at 45 degrees, with the exit direction forming a 90-degree angle with the P-polarized light.

Specifications

ParameterValue
Single-wavelength polarizing beamsplitter prism-AR coating (R) [per surface]R<0.2 % per surface
Single-wavelength polarizing beamsplitter prism-Tp-polTp> 95 %
Single-wavelength polarizing beamsplitter prism-Rs-polRs> 99.8 %
Single-wavelength polarizing beamsplitter prism-Extinction ratio (Tp / Ts)Tp / Ts>1000 : 1
Broadband polarizing beamsplitter prism-AR coating (R) [per surface]R<0.5 % per surface
Broadband polarizing beamsplitter prism-Tp-polTp> 90 %
Broadband polarizing beamsplitter prism-Rs-polRs> 99.5 %
Broadband polarizing beamsplitter prism-Extinction ratio (Tp / Ts)Tp / Ts>500 : 1
