In-line Faraday Rotator
The In-line Faraday Rotator rotates the polarization of the input light by 45 degrees. It performs with low insertion loss, high extinction ratio, high return loss and excellent environmental stability. It is used in sensors, circulators, amplifiers, lasers, etc. It is a bi-directional device
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Operating Wavelength Range [without connectors] | 1310 nm, 1480 nm or 1550 nm |
| Typ. Insertion Loss [without connectors] | ±20 dB |
| Max. Insertion Loss [without connectors；Typ. A] | 0.3 dB |
| Max. Insertion Loss [without connectors；Typ. B] | 0.5 dB |
| Min. Return Loss [without connectors；Typ. A] | 0.5 dB |
| Min. Return Loss [without connectors；Typ. B] | 0.7 dB |
| Min. Extinction Ratio [without connectors；Slow Axis of Port 1 is aligned to Slow Axis of Port 2, at 23°C；Typ. A] | 20 (Slow Axis of Port 1 is aligned to Slow Axis of Port 2, at 23 °C) |
| Min. Extinction Ratio [without connectors；Slow Axis of Port 1 is aligned to Fast Axis of Port 1, at 23°C；Typ. B] | 20 (Slow Axis of Port 1 is aligned to Fast Axis of Port 1, at 23 °C) |
| Min. Extinction Ratio [without connectors；Slow Axis of Port 2 is aligned to Fast Axis of Port 1, at 23°C；Typ. A] | 20 (Slow Axis of Port 2 is aligned to Fast Axis of Port 1, at 23 °C) |
| Rotation Angle at 23°C, λc (λ) [without connectors；23°C；λc] | 45±1 |
| Max. Optical Power (CW) [without connectors；CW] | 500 mW |
| Max. Tensile Load [without connectors] | 5 N |
| Operating Temperature [without connectors] | -5 to +70 °C |
| Storage Temperature [without connectors] | -40 to +85 °C |
