High-speed low-noise PV balance detector MBD series
The high-speed low-noise photobalance detection module brings together two matching ultra-low-noise analogue PIN detectors, low-noise broadband cross-debris amplifiers and ultra-low-noise power sources; features such as high multipliers, high sensitivity, high broadband, low-noise, high-mode inhibition ratios; commodular noise that can effectively reduce signals; and increasing the system ' s noise ratio. Low noise, high bandwidth, high gain, high sensitivity, tight structure, custom, high commo
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| bandwidth | DC~100M; DC~200M; DC~350M; AC~800M; AC~1.6G; MHZ |
| Detector Response | 0.95@1550nm; A/W |
| Cross-Restruction Gains | 60K (30 options); 30K (60k options); 30K/7000; V/A |
| Saturation input photopower | 100; 150; 150; 150/2000; uW |
| Output Interdiction | 50; 50; 50; 50; 50; Ω |
| Output voltage Noise | 10（Typical）; 10（Typical）; 25（Typical）; mVpp |
| Output coupling method | DC/AC; D; C/AC; DC/AC; AC; AC |
| Electricity voltage | 5; 5; 5; 12; 12; V |
| Power supply | 0.5(max); A |
| Optical input | FC/APC |
| Radio frequency output | SMA |
