AutoSmart M

Connector: LC Wavelength: LWDM4

Sensor Range: -35 to 250 °C (-31 to 482 °F) Field of View: 6 ° (10:1) approximately Minimum Spot Size: 20 mm (0.8")

The AutoSmart processes the mV signal from any IRt/c or Micro IRt/c model, linearizes the signal and gives an analog output (4-20mA, 0-5V, 0-10V). No Impedance, leakage current, or linearity problems to worry about You can chose your range: 0-100C or 0-2050C target temperature. Custom calibrations are offered.

Sensor Range: 50 to 250 °C (122 to 482 °F) Field of View: 14 ° (4:1) approximately Minimum Spot Size: 3 mm (0.1")

The AutoSmart processes the mV signal from any IRt/c or Micro IRt/c model, linearizes the signal and gives an analog output (4-20mA, 0-5V, 0-10V). No Impedance, leakage current, or linearity problems to worry about You can chose your range: 0-100C or 0-2050C target temperature. Custom calibrations are offered.

The IRT101M infrared temperature measurement module uses the principle of infrared radiation (IR) to measure the temperature of the target object. It adopts a UART digital interface output for ease of use and has a wide temperature measurement range (the range can be adjusted according to actual needs). This module is manufactured by closely combining mature infrared temperature measurement technology with precise optical path design and refined circuit design.
