800-1,000 m J 1535 nm glass laser
The working wavelength of 1535 nm glass lasers is a human eye safety band; they have great advantages in areas such as laser ranging, radar, etc. The laser pulse of this series is pure and clean; the single pulse energy is stable; the beam is of good quality. Integrated design for semiconductor pump modules and laser crystals; small and compact seals to facilitate installation and integration; output energy up to 1 mJ for this series of products
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Energy stability | 3% |
| All over the corner | ≤7mrad |
| Beam Mode | TEM00 |
| Weight | 13g |
| Wavelength | 1535nm |
| Single pulse energy | 800; 1000μJ |
| Repeat frequency | 10; 5Hz |
Applications
Key Features
Datasheet
