11RTR Semiconductor Laser Model
11RTR is a multifunctional laser module for the AW series of almonds; single tube core fibre-optic extraction design; easy to maintain; power stability. Configure the functions of indicator light, fibre-optic switches, PD detectors, heat-sensitive electrical resistance, etc
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 0.5; 10; 15; 5W |
| He's on the wavelength | ±10nm |
| spectral width | <4nm |
| Wave length with temperature properties | 0.3nm/°C |
| Microefficiency | 0.7; 0.8; 0.9; 0.3W/A |
| Electricity | <8000μA |
| Heat-sensitive electrical resistance parameters (beta per second) | 10±1%/3930 |
| Fibre core diameter | 200 / 220μm |
| Numerical aperture | 0.22 |
| Connector | SMA905 |
| Central wavelength | 638; 808; 940 / 980; 1064; 1470nm |
