1.5-2mJ 1535nm glass laser
The working wavelength of 1535 nm glass lasers is a human eye safety band; they have great advantages in areas such as laser ranging, radar, etc. The laser pulse of this series is pure and clean; the single pulse energy is stable; the beam is of good quality. Integrated design for semiconductor pump modules and laser crystals; small and compact envelopes to facilitate installation and integration; output energy up to 2 mJ for this series of products
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Pumping veins wide | ≤3ms |
| Energy stability | 3% |
| @photographic diameter typ.(mm@1/e2) | 0.45mm |
| All over the corner | ≤5.5; ≤6mrad |
| Beam Mode | TEM00 |
| @PD typ | 3V |
| Weight | 100g |
| Signal | Internal photodial diode |
| Wavelength | 1535nm |
| Single pulse energy | 2; 1.5 |
| Repeat frequency | 1; 5; 10Hz |
Applications
Key Features
Datasheet
