08LTR space narrow line semiconductor laser module
08LTR Space Cover Models are star products of the Apricotian Wisdom NL narrow-line wide laser product line; the product is based on VBG lockwave technology; compatible with TEC sealing; achieves a stable power output and a high margin inhibition ratio; has a good temperature wavelength drift feature; multiple wavelengths are optional; small size; especially for handheld equipment
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 500; 600; 800mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1; <0.3nm |
| Wave length with temperature properties | 0.01nm/°C |
| Wave length with current properties | 0.05nm/A |
| Microefficiency | 0.8; 0.9; 0.7W/A |
| Electricity | <2000μA |
| Heat-sensitive electrical resistance parameters | 10±1%/3930 |
| Maximum voltage | 6.3V |
| Central wavelength | 638; 785; 808; 830; 981; 1064nm |
