08LTR-mini single-mode space narrow line semiconductor laser module
08LTR-mini is a narrow-width semiconductor laser module for the single-mode space series of apricot simulators. The product is based on the VBG lock wave technology for single-module chips; built-in TEC chillers, PD PV detectors, RT heat-sensitive electrical resistance; a stable lock-out output in a continuous working pattern; characteristics such as line width, output stability, temperature drift, small size, etc.; especially applicable to the Laman spectral analysis industry
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 100; 300mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1nm |
| Wave length with temperature properties | 0.01nm/°C |
| Wave length with current properties | 0.05nm/A |
| Microefficiency | 0.8; 0.7W/A |
| Electricity | <2000μA |
| Heat-sensitive electrical resistance parameters | 10 |
| Maximum voltage | 4.2V |
| Central wavelength | 785; 1064nm |
Applications
Key Features
Datasheet
