04BCK Single-mode narrow line wide semiconductor laser module
04BCK containment module is a star product of the Apricot Wisdom NL narrow-width laser product line; the product is a single-model laser output; it has good temperature wavelength drifting properties; it also has very small outer dimensions; and it is especially suitable for wear applications for the Laman detection equipment
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 100mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1nm |
| Wave length with temperature properties | ≤0.01nm/°C |
| Microefficiency | 0.9W/A |
| Heat-sensitive electrical resistance parameters | 10±5%/3450 |
| Central wavelength | 785nm |
| Maximum voltage | 2.5V |
Applications
Key Features
Datasheet
