7500 W water cold and semiconductor side pump module
The 7500W water cooling and semiconductor side-pump module of almonds is based on the WA series of water cooling and semiconductor laser arrays of almonds as core elements; can achieve peak power pumps, high gain output; and effectively inhibit the ASE effect. Products have characteristics such as good beam quality, compact structure, low thermal effects; they are widely used in solid lasers Medium
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Pumping Peak Power | 6000; 7500W |
| Crystal material | Nd:YAG |
| Number of bars | 30 |
| Pumping wavelength | 808±3nm |
| Working mode | QCW |
| Percentage | ≤3% |
| Repeat frequency | ≤100Hz |
| Water flow | 10~15L/min |
| Water pressure | <0.5MPa |
| Refrigerated fluid | Distilled water |
| Temperature range | 10~35℃ |
| Storage temperature range | -10~50℃ |
