7,200W Transmitting semiconductor side pump module
The 7,200W conductive semiconductor side-pump module of the apricot-wise apricot-wise PA-2 series of polygons uses the apricot-wise cooling array and laser crystals that weld with heat as core elements; water-free from cooling; it responds to harsh operating environments; and it allows for miniaturized peak power pumps. Products have the characteristics of good beam quality, stability and low thermal effects; they are widely applied to solid lasers in harsh environments, such as on-board and on-
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Pumping Peak Power | 4800; 6000; 7200W |
| Crystal material | Nd:YAG |
| Number of crystals | 2 |
| Number of bars | 48; 60; 72 |
| Pumping wavelength | 808±3nm |
| Working mode | QCW |
| Percentage | ≤0.6% |
| Repeat frequency | ≤20Hz |
| Temperature range | -40~65℃ |
| Storage temperature range | -45~80℃ |
Applications
Key Features
Datasheet
