Aqueous semiconductor laser arrays in the WA-4 series
The WA-4 series of water cooling semiconductor laser arrays is a high-value water cooling array product developed by apricot-wise light; consists of four sets of stacked one-lined arrays; each group consists of 1.3 bar bars; single bar power 100 ~ 250 W; and a quasi-continuous output can be achieved. More wavelength combinations and packagings are customised
Specification Snapshot
Every working voltage
≤2.1V
Request a Quote
Download Datasheet
Overview
The WA-4 series of water cooling semiconductor laser arrays is a high-value water cooling array product developed by apricot-wise light; consists of four sets of stacked one-lined arrays; each group consists of 1.3 bar bars; single bar power 100 ~ 250 W; and a quasi-continuous output can be achieved. More wavelength combinations and packagings are customised
Specifications
| Parameter | Value |
|---|---|
| Optical Parameters | max: 1200; max: 2000 |
| Electricity conversion efficiency | ≥50% |
| Every working voltage | ≤2.1V |
| Percentage | ≤3% |
| Repeat frequency | ≤100Hz |
| Water flow | ≥3L/min |
| Water pressure | ≤0.5MPa |
| Working temperature range | 10~40℃ |
Applications
Industrial pump; biomedical; scientific research
Key Features
Encapsulated structures compact; hard welded seals; peak power; high reliability
Datasheet
Product Datasheet
PDF
Supplier Information
Beijing RealLight Technology Co., Ltd. was founded in 2010 and is a high-tech enterprise specializing in the independent research and development, production, and sales of semiconductor lasers, microchip lasers, erbium glass lasers, high-power solid-state lasers, high-energy lamp-pumped lasers, and supporting components.
The company has a large and innovative engineering and technical team. After years of technical accumulation and process precipitation, RealLight has gained professional capabilities in laser design, chip packaging, device packaging, system integration, etc., and has successfully completed a number of technological innovation projects and model equipment projects, and has obtained multiple qualification certifications, patent works, and product certifications.
We have provided many innovative and competitive products to customers in various fields such as analytical instruments, biomedical, radar ranging, laser processing, etc. At the same time, we can also provide customized overall solutions and high-quality services according to customer needs.
RealLight looks forward to becoming your partner and creating value for you with laser technology!
