PA-2 series polygonal conductor semiconductor laser arrays
The PA-2 series of polygonal conductor semiconductor laser arrays is a high-value power product developed by almonds at high temperatures (60°C). PA-2 consists of 12 sets of folded hexagonal rectangles; a single group of 1-4 bar bars; and a single bar power of 100 W/200W. Other wavelengths, packagings are customised
Specification Snapshot
Wave temperature drift factor
~0.3nm/°C
Every working voltage
≤2.1V
Request a Quote
Download Datasheet
Overview
The PA-2 series of polygonal conductor semiconductor laser arrays is a high-value power product developed by almonds at high temperatures (60°C). PA-2 consists of 12 sets of folded hexagonal rectangles; a single group of 1-4 bar bars; and a single bar power of 100 W/200W. Other wavelengths, packagings are customised
Specifications
| Parameter | Value |
|---|---|
| Central wavelength range | ±3nm |
| Each output power | 100; 200W |
| Horizontal arrays | 2 |
| Horizontal Array Group spacing | 3mm |
| Number per group | 1~4; 1~3 |
| Space | 0.43; 0.55mm |
| spectral width | ≤6nm |
| Quick-axis split | 40 |
| Slow-axis Shape | 10 |
| Wave temperature drift factor | ~0.3nm/°C |
| Central wavelength | 790~812nm |
| Electricity conversion efficiency | ≥50% |
| Every working voltage | ≤2.1V |
| Percentage | ≤0.8%@4800W; ≤0.6%@7200W |
| Repeat frequency | ≤25; ≤20Hz |
| Working temperature range | -40~65℃ |
Applications
Laser pumps; laser lighting; laser processing; scientific research
Key Features
Hard weld seals; high temperature applications; peak power; high reliability
Datasheet
Product Datasheet
PDF
Supplier Information
Beijing RealLight Technology Co., Ltd. was founded in 2010 and is a high-tech enterprise specializing in the independent research and development, production, and sales of semiconductor lasers, microchip lasers, erbium glass lasers, high-power solid-state lasers, high-energy lamp-pumped lasers, and supporting components.
The company has a large and innovative engineering and technical team. After years of technical accumulation and process precipitation, RealLight has gained professional capabilities in laser design, chip packaging, device packaging, system integration, etc., and has successfully completed a number of technological innovation projects and model equipment projects, and has obtained multiple qualification certifications, patent works, and product certifications.
We have provided many innovative and competitive products to customers in various fields such as analytical instruments, biomedical, radar ranging, laser processing, etc. At the same time, we can also provide customized overall solutions and high-quality services according to customer needs.
RealLight looks forward to becoming your partner and creating value for you with laser technology!
