PA-1 series polygonal conductor semiconductor laser arrays
The PA-1 series of polygonal conductor semiconductor laser arrays are high-value power products developed by almonds with light at high temperatures (60°C). PA-1 consists of six sets of folded hexagonal rectangles; one group of 1-4 bar; and one bar power of 100 W/200 W. Other wavelengths, packagings are customised
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Central wavelength range | ±3nm |
| Each output power | 100; 200W |
| Number per group | 1~4; 1~3 |
| Space | 0.43; 0.55mm |
| spectral width | ≤6nm |
| Quick-axis split | 40 |
| Slow-axis Shape | 10 |
| Wave temperature drift factor | ~0.3nm/°C |
| Central wavelength | 790~812nm |
| Electricity conversion efficiency | ≥50% |
| Every working voltage | ≤2.1V |
| Percentage | ≤0.8%@2400W; ≤0.6%@3600W |
| Repeat frequency | ≤25; ≤20Hz |
| Working temperature range | -40~65℃ |
