GS12 Cool Vertical Array
GS12 Transmitting the cooling vertical array is a device developed by almonds with light and applied in a wide temperature range. It has high peak power, small size and easy integration characteristics
Specification Snapshot
Wave temperature drift factor
~0.3nm/°C
Every working voltage
≤2.1V
Request a Quote
Download Datasheet
Overview
GS12 Transmitting the cooling vertical array is a device developed by almonds with light and applied in a wide temperature range. It has high peak power, small size and easy integration characteristics
Specifications
| Parameter | Value |
|---|---|
| Central wavelength range | ±5; ±3nm |
| Each output power | 100; 200W |
| Laser Bar Count | 1~2; 3~6; 2~4 |
| Space | 0.8; 0.43; 0.55mm |
| spectral width | ≤5nm |
| Quick-axis split | 40 |
| Slow-axis Shape | 10 |
| Wave temperature drift factor | ~0.3nm/°C |
| Central wavelength | 940; 790~812nm |
| Electricity conversion efficiency | ≥50% |
| Every working voltage | ≤2.1V |
| Percentage | ≤3%@200W; ≤0.8%@600W; ≤0.6%@800W |
| Repeat frequency | 1~10; 1~25; 1~20Hz |
| Working temperature range | -40~65℃ |
Applications
Pumping pots; scientific research
Key Features
Hard weld seal; peak power; high reliability; multi-wavelength integration
