GS07 Transmitting semiconductor laser arrays
A semiconductor laser array in the form of GS07 is a miniaturized, multiwave long product (70°C) used under the apricot development; it can also be a single wavelength output; bar length 5mm; monobar power 150-200W; 15 bar bars can be sealed; other wavelengths, sealing forms can be customised
Specification Snapshot
Wave temperature drift factor
~0.3nm/°C
Every working voltage
<2.1V
Request a Quote
Download Datasheet
Overview
A semiconductor laser array in the form of GS07 is a miniaturized, multiwave long product (70°C) used under the apricot development; it can also be a single wavelength output; bar length 5mm; monobar power 150-200W; 15 bar bars can be sealed; other wavelengths, sealing forms can be customised
Specifications
| Parameter | Value |
|---|---|
| Central wavelength | 796~808nm |
| Central wavelength range | ±3nm |
| Each output power | 180W |
| Laser Bar Count | 1~15 |
| Space | ~0.4mm |
| spectral width | ≤5nm |
| Per slope efficiency | >1.0W/A |
| Quick-axis split | 40 |
| Slow-axis Shape | 12 |
| Wave temperature drift factor | ~0.3nm/°C |
| Electricity conversion efficiency | >50% |
| Every working voltage | <2.1V |
| Percentage | <0.8% |
| Repeat frequency | <30Hz |
| Working temperature range | -40~75℃ |
Applications
Laser pumps; laser lighting; laser processing; scientific research
Key Features
Hard weld wrapping; tight structure; peak power density; high reliability
Datasheet
Product Datasheet
PDF
Supplier Information
Beijing RealLight Technology Co., Ltd. was founded in 2010 and is a high-tech enterprise specializing in the independent research and development, production, and sales of semiconductor lasers, microchip lasers, erbium glass lasers, high-power solid-state lasers, high-energy lamp-pumped lasers, and supporting components.
The company has a large and innovative engineering and technical team. After years of technical accumulation and process precipitation, RealLight has gained professional capabilities in laser design, chip packaging, device packaging, system integration, etc., and has successfully completed a number of technological innovation projects and model equipment projects, and has obtained multiple qualification certifications, patent works, and product certifications.
We have provided many innovative and competitive products to customers in various fields such as analytical instruments, biomedical, radar ranging, laser processing, etc. At the same time, we can also provide customized overall solutions and high-quality services according to customer needs.
RealLight looks forward to becoming your partner and creating value for you with laser technology!
