CA01 ring-conductor semiconductor laser arrays

CA01 ring-conductor semiconductor laser arrays

Supplier
Real-light
Category
Laser Diodes
Origin
China

The CA01 ring-conductor semiconductor laser array is a high-value power product developed by almonds with high temperature (60°C). CA01 consists of a number of bar-cylinders; monobaric power 100W/200W. Other wavelengths, packagings are customised

Specification Snapshot
Wave temperature drift factor
~0.3nm/°C
Every working voltage
≤2.1V
Request a Quote Download Datasheet
Save to Favorites Save to Favorites

Overview

The CA01 ring-conductor semiconductor laser array is a high-value power product developed by almonds with high temperature (60°C). CA01 consists of a number of bar-cylinders; monobaric power 100W/200W. Other wavelengths, packagings are customised

Specifications

ParameterValue
Central wavelength range±3nm
Each output power100; 200W
Horizontal arraysCustomise
Horizontal Array Group spacingCustomise
Number per groupCustomise
SpaceCustomise
spectral width<6nm
Quick-axis dispersing≤40
The slow-axis dispersing angle≤10
Wave temperature drift factor~0.3nm/°C
Central wavelength790~812nm
Electricity conversion efficiency≥50%
Every working voltage≤2.1V
Percentage<0.8%
Repeat frequency≤25; ≤20Hz
Working temperature range-40~65℃

Applications

Laser pumps; laser lighting; laser processing; scientific research

Key Features

Hard weld seals; high temperature applications; peak power; high reliability

Datasheet

Product Datasheet
PDF
Download

Supplier Information

Re
Real-light
View Supplier →
Beijing RealLight Technology Co., Ltd. was founded in 2010 and is a high-tech enterprise specializing in the independent research and development, production, and sales of semiconductor lasers, microchip lasers, erbium glass lasers, high-power solid-state lasers, high-energy lamp-pumped lasers, and supporting components. The company has a large and innovative engineering and technical team. After years of technical accumulation and process precipitation, RealLight has gained professional capabilities in laser design, chip packaging, device packaging, system integration, etc., and has successfully completed a number of technological innovation projects and model equipment projects, and has obtained multiple qualification certifications, patent works, and product certifications. We have provided many innovative and competitive products to customers in various fields such as analytical instruments, biomedical, radar ranging, laser processing, etc. At the same time, we can also provide customized overall solutions and high-quality services according to customer needs. RealLight looks forward to becoming your partner and creating value for you with laser technology!
