AWSO-B series multi-wave-long semiconductor laser module
The AWSO-B series multi-wave long-range semiconductor laser module is designed to integrate mono-modular fibre-optic coupling laser modules, multi-channel-driven circuits designed for almond luminous and self-design; input-output interfaces that match standards; user-host systems that can be easily embedded; and multi-wave long, multi-channel semiconductor laser outputs that achieve high stability and compact structure. At the same time; our Division can provide design customization services suc
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| One-way mode continuous output power | 50; 60mW |
| He's on the wavelength | ±10nm |
| spectral width | <3nm |
| Wave length with temperature properties | 0.3nm/°C |
| Luminous Mode | Monochrome |
| Model Arrange | 49 out of 36 |
| Fibre core diameter | 4/125, 6/125, 9/125μm |
| Numerical aperture | 0.14 |
| Fibre length | 200±5cm |
| Plugin specification | SMART 905 long metal pin (50 mm long, outer diameter: 3.17 mm) |
| Working mode | Continuous/quasi-continuous |
| Light frequency | 0~2kHz |
| The light's wide | <40ms |
| Working hours | <45min |
| Temperature | Internal TEC refrigeration, real-time temperature monitoring |
| Control Mode | Each group is independently controlled to achieve synchronized output |
| Working environment temperature | 10~35℃ |
| Storage temperature requirements | -25~55℃ |
| Storage Humidity Requirements | 0~80% RH |
| Central wavelength | 405; 450; 520; 638; 650nm |
