14SBTF space narrow line wide semiconductor laser module
14SBTF Space Encapsulation Models are star products of the Apricot Wisdom NL narrow-line laser line; the product is based on VBG lock wave technology; compatible with TEC sealing; achieves stable power output and high border depressive ratio; has good temperature wavelength drift; multiple wavelengths are optional
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 500; 600; 800mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1; <0.3nm |
| Wave length with temperature properties | 0.01nm/°C |
| Wave length with current properties | 0.05nm/A |
| Border Model Impression Ratio | >35; >40dB |
| Microefficiency | 0.8; 0.9; 0.7W/A |
| Electricity | <2000μA |
| Heat-sensitive electrical resistance parameters | 10±1%/3930 |
| Maximum voltage | 6.3V |
| Central wavelength | 638; 785; 808; 830; 981; 1064nm |
