14HHL Semiconductor Laser Model
14HHL is a multifunctional AW series of multi-purpose lasers; single tube core, fibre-optic plug-in output design. Configure the functions of indicator light, fibre-optic switches, PD detectors, heat-sensitive electrical resistance, etc
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 4; 9; 15; 10; 5W |
| He's on the wavelength | ±10nm |
| spectral width | <4nm |
| Wave length with temperature properties | 0.3nm/°C |
| Output Power | 2mW |
| The wavelength | 650±10nm |
| Microefficiency | 1.1; 0.9; 0.4W/A |
| Electricity | <3000μA |
| Heat-sensitive electrical resistance parameters | 10±1%/3930 |
| Maximum voltage | 9.8V |
| Fibre core diameter | 105/125, 200/220, 400/440μm |
| Numerical aperture | 0.22 |
| Connector | SMA905 |
| Central wavelength | 450; 808; 940/976/980; 1064; 1470nm |
